DIPTRONICS NDIR-05H-V, SWITCH DIP 5 Pos. SPST 25mA 24VDC THT V/T

NDIR-05H-V
brand logo

HT Part No. HT254857

Mfr. Part No. NDIR-05H-V

Manufacturer: DIPTRONICS

Technical Documents: Datasheet(datasheets)

327 - In Stock pcs
Price:
£ 0.59
Units Per Unit Price
1 - 34 £ 0.59
35 + £ 0.52
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Mounting Type THT V/T
Operating Temperature -20°C~+85°C
Number of Positions 5
Voltage Rating (DC) 24V
Orientation Top Actuated
Washable No
Manufacturer DIPTRONICS
Series NDI
Current Rating (DC) 25mA
Housing Color Black
Rohs ROHS
Circuit SPST
Current Rating (AC) None
Voltage Rating (AC) None
Features N/A
Packaging TUBE
Keyword dıp siviç, dıp anahtar

More Information

The DIPTRONICS NDIR-05H-V is a compact and versatile 5-position single-pole single-throw (SPST) DIP switch designed for efficient circuit configuration and control. This through-hole technology (THT) component offers reliable performance with a 25mA current rating and a voltage rating of 24VDC. Its user-friendly design allows for easy manual switching between different circuit states, making it an ideal solution for a wide range of applications.

Standout Features of the DIPTRONICS NDIR-05H-V, 5-Position Switch SPST

  • Compact DIP package for space-saving installation
  • SPST design for simple circuit control
  • Through-hole technology (THT) for reliable soldering

Benefits for You

  • Easy manual switching between circuit states
  • Versatile for various circuit configurations
  • Reliable performance in demanding environments
  • Cost-effective solution for circuit control

Usage Information of the 5-Position Switch SPST

  • Microcontroller Configuration
  • Memory Selection
  • Address Decoding
  • Test Point Selection
  • Voltage Level Switching
