LEM LF 505-S, TRANSDUCER CURRENT 500A HALL EFFECT,CLOSED LOOP

LF 505-S
brand logo

HT Part No. HT257717

Mfr. Part No. LF 505-S

Manufacturer: LEM

Technical Documents: Datasheet(datasheets)

7102 - In Stock pcs
Price:
£ 0
Units Per Unit Price
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Mounting Type Free
Technology Hall Effect,Closed Loop
Applications N/A
Primary Signal Type AC/DC
Primary Nominal Value 500A
Connversion Ratio 1:5000
Current Range (Max) ±800A
Voltage Range (Max) None
Operating Temperature -40°C ~ +70°C
Supply Voltage ±15~±24VDC
Frequency 0 ~ 100KHz
Response Time 1us
Rohs ROHS
Packaging BOX
Manufacturer LEM
Secondary Signal 100mA
Sensitivity None

More Information

The LEM LF 505-S is a state-of-the-art current transducer utilising Hall Effect technology within a closed-loop system. It accurately measures currents up to 500A by sensing the magnetic field produced by the current-flow through a conductor, ensuring precise and reliable measurement without altering the primary circuit. This transducer is renowned for its high accuracy and stability, making it ideal for applications demanding precise current monitoring in industrial and commercial environments.

Crucial Features and Benefits of Using the LEM LF 505-S, Transducer Current 500A Hall Effect, Closed Loop

  • Closed-loop design ensures minimal insertion loss and precise output.
  • Compact size with easy integration into existing systems.
  • Provides accurate and reliable current measurement for critical applications.
  • Ensures safety and efficiency by monitoring high currents with precision.
  • Reduces installation complexity and maintenance costs.
  • Offers real-time monitoring capabilities for improved process control.
  • Enhances system performance and longevity with robust design and high-quality components.

Application Areas of the Transducer Current

  • Industrial Automation and Robotics
  • Power Distribution Systems and Renewable Energy
  • Electric Vehicles and Charging Stations
  • Battery Management Systems
  • Welding Equipment and Process Control
