LEM HC2F-80-S, TRANSDUCER CURRENT 80A HALL EFFECT,OPEN LOOP,AUTO

HC2F 80-S
brand logo

HT Part No. HT257714

Mfr. Part No. HC2F 80-S

Manufacturer: LEM

Technical Documents: Datasheet(datasheets)

1 - In Stock pcs
Price:
£ 31.15
Units Per Unit Price
1 - 53 £ 31.15
54 + £ 29.11
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Frequency 0 ~ 20KHz
Manufacturer LEM
Technology Hall Effect,Open Loop
Operating Temperature -40°C ~ +125°C
Supply Voltage 5VDC
Sensitivity 25mV/A
Applications N/A
Mounting Type THT
Primary Signal Type AC/DC
Voltage Range (Max) None
Response Time 15us
Connversion Ratio None
Primary Nominal Value 80A
Secondary Signal 2V
Current Range (Max) ±80A
Rohs N/A
Packaging BOX

More Information

The LEM HC2F-80-S is a current transducer utilising Hall Effect technology, designed to accurately measure electrical currents up to 80A in open-loop configurations, ideal for automated systems. It offers precise current measurement, ease of installation, versatility, and safety enhancements, making it a reliable choice across various industrial and electrical applications.

Crucial Features of the LEM HC2F-80-S, Current Transducer

  • Hall Effect technology for precise current measurement.
  • Open-loop design simplifies installation and integration.
  • Auto-ranging capability adjusts to varying current levels.
  • Compact size with robust build quality for reliability.
  • High isolation voltage ensures safety and signal integrity.

Benefits You Get

  • Accurate current measurement without needing direct contact with the conductor.
  • Simplified installation and maintenance due to open-loop operation.
  • Versatile auto-ranging feature adapts to different current ranges.
  • Enhanced safety with high isolation voltage, suitable for industrial applications.

The LEM HC2F-80-S, Current Transducer: Versatility in Applications

  • Industrial Automation and Control Systems
  • Power Supplies and Battery Management
  • Renewable Energy Systems Monitoring
  • Electric Vehicle Charging Systems
  • HVAC Systems and Motor Control
