LEM HLSR 20-P, TRANSDUCER CURRENT 20A HALL EFFECT,OPEN LOOP

HLSR 20-P
brand logo

HT Part No. HT257713

Mfr. Part No. HLSR 20-P

Manufacturer: LEM

Technical Documents: Datasheet(datasheets)

1063 - In Stock pcs
Price:
£ 5.42
Units Per Unit Price
1 - 49 £ 5.42
50 + £ 4.93
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Rohs ROHS
Mounting Type THT
Primary Signal Type AC/DC
Primary Nominal Value 20A
Frequency 0 ~ 100KHz
Manufacturer LEM
Supply Voltage 5VDC
Current Range (Max) ±50A
Sensitivity 40mV/A
Response Time 2.5us
Applications N/A
Connversion Ratio 20A : 800mV
Technology Hall Effect,Open Loop
Secondary Signal 800mV
Voltage Range (Max) None
Operating Temperature -40°C ~ +105°C
Packaging TRAY

More Information

The LEM HLSR 20-P is a high-precision current transducer utilizing Hall Effect technology in an open-loop configuration. It accurately measures currents up to 20A by detecting the magnetic field generated by the current flow through a conductor without the need for electrical contact. This non-intrusive method ensures minimal impact on the circuit being measured, making it suitable for applications where precise current monitoring is critical.

What Are the Possible Advantages of Using the LEM HLSR 20-P, Current Transducer

  • Compact design with easy integration into existing systems.
  • High accuracy and linearity over a wide temperature range.
  • Enables precise monitoring of current without interrupting the circuit.
  • Provides galvanic isolation, enhancing safety and reliability.
  • It supports high-accuracy measurements that are crucial for industrial applications.
  • Compact size saves space and facilitates installation in cramped environments.
  • Reliable performance across varying environmental conditions.

Versatile Uses of the LEM HLSR 20-P, Transducer Current 20A Hall Effect, Open Loop

  • Industrial Automation and Control Systems
  • Power Distribution and Management in Electrical Panels
  • Solar and Wind Power
  • Battery Management Systems in Electric Vehicles
  • Monitoring Equipment in HVAC Systems
