LEM HO 120-P-0100, TRANSDUCER CURRENT 120A HALL EFFECT,OPEN LOOP

HO 120-P-0100
brand logo

HT Part No. HT257656

Mfr. Part No. HO 120-P-0100

Manufacturer: LEM

Technical Documents: Datasheet(datasheets)

207 - In Stock pcs
Price:
£ 17.58
Units Per Unit Price
1 - 24 £ 17.58
25 + £ 16.43
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Packaging TRAY
Primary Signal Type AC/DC
Secondary Signal 800mV
Rohs ROHS
Connversion Ratio None
Primary Nominal Value 120A
Response Time 3.5us
Manufacturer LEM
Mounting Type THT
Technology Hall Effect,Open Loop
Supply Voltage 5VDC
Voltage Range (Max) None
Frequency 0 ~ 100KHz
Current Range (Max) ±300A
Sensitivity 6.667mV/A
Applications N/A
Operating Temperature -40°C ~ +105°C

More Information

The LEM HO 120-P-0100 is a current transducer utilising Hall effect technology designed for measuring electrical currents up to 120A in open-loop configurations. It converts the primary current flowing through a conductor into a proportional electrical signal, ensuring accurate monitoring without disrupting the circuit. This device is recognised for its precision and reliability in industrial and electronic applications where real-time current monitoring is critical for operational safety and efficiency.

What Are the Possible Advantages of the LEM HO 120-P-0100, Current Transducer?

  • Hall effect sensing technology for accurate current measurement.
  • Open-loop design eliminates the need for additional power supplies.
  • Compact and robust construction suitable for harsh environments.
  • Low insertion loss and minimal phase shift for precise readings.
  • Enables real-time current monitoring without interrupting the circuit.
  • High accuracy and reliability ensure consistent performance.
  • Simplifies installation with its open-loop configuration.
  • Suitable for both AC and DC current measurements.
  • Long-term stability reduces maintenance costs and downtime.

The LEM HO 120-P-0100, Current Transducer: Wide Application Range

  • Industrial automation and control systems.
  • Solar and wind power.
  • Electric vehicle charging stations.
  • Power distribution units and UPS systems.
  • Precision instrumentation and testing equipment.
