LEM HC5FW 800-S, TRANSDUCER CURRENT 800A HALL EFFECT,OPEN LOOP,AUTO

HC5FW 800-S
brand logo

HT Part No. HT257651

Mfr. Part No. HC5FW 800-S

Manufacturer: LEM

Technical Documents: Datasheet(datasheets)

191 - In Stock pcs
Price:
£ 29.07
Units Per Unit Price
1 - 9 £ 29.07
10 + £ 27.17
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Secondary Signal 2V
Operating Temperature -40°C ~ +125°C
Supply Voltage 5VDC
Primary Signal Type AC/DC
Technology Hall Effect,Open Loop
Voltage Range (Max) None
Manufacturer LEM
Mounting Type THT
Current Range (Max) ±800A
Frequency 0 ~ 40KHz
Connversion Ratio None
Primary Nominal Value 800A
Sensitivity 2.5mV/A
Response Time 2us
Applications Automotive
Rohs ROHS
Packaging BOX

More Information

The LEM HC5FW 800-S is a current transducer utilising Hall Effect technology to measure currents up to 800A accurately. It operates in an open-loop configuration with automatic functionality, ensuring precise current measurement without the need for additional circuitry.

Advanced Attributes and Advantages of Using the LEM HC5FW 800-S, Current Transducer

  • Hall Effect sensor technology for accurate current measurement.
  • Open-loop design simplifies integration and reduces complexity.
  • Automatic functionality for ease of operation.
  • Compact size suitable for various installation environments.
  • Wide temperature range for versatile application scenarios.
  • Accurate and reliable current measurement up to 800A.
  • Simplified installation and integration due to the open-loop design.
  • Automatic operation reduces manual intervention, enhancing efficiency.
  • Robust construction ensures durability and longevity.
  • Suitable for both industrial and automotive applications.

Versatile Uses of the Current Transducer

  • Industrial machinery monitoring and control.
  • Renewable energy systems for current monitoring.
  • Automotive battery management and traction systems.
  • Power distribution systems in data centres and telecom infrastructure.
  • Testing and measurement equipment where precise current measurement is critical.
