LA125-P - TRANSDUCER CURRENT 125A HALL EFFECT,CLOSED LOOP

LA125-P
brand logo

HT Part No. HT257634

Mfr. Part No. LA125-P

Manufacturer: LEM

Technical Documents: Datasheet(datasheets)

45 - In Stock pcs
Price:
£ 38.93
Units Per Unit Price
1 - 7 £ 38.93
8 + £ 36.38
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Primary Nominal Value 125A
Mounting Type THT
Connversion Ratio 1:1000
Applications N/A
Technology Hall Effect,Closed Loop
Secondary Signal 125mA
Current Range (Max) ±200A
Manufacturer LEM
Primary Signal Type AC/DC
Supply Voltage ±12~±15VDC
Sensitivity None
Packaging BOX
Voltage Range (Max) None
Frequency 0 ~ 100KHz
Response Time 1us
Operating Temperature -40°C ~ +85°C
Rohs ROHS

More Information

The LA125-P by LEM is a high-accuracy, closed-loop Hall effect current transducer designed for measuring both AC and DC currents up to 125A. It provides galvanic isolation between the primary and secondary circuits, ensuring safety and eliminating ground loop currents.

Special Features and Benefits of LA125-P – LEM Current Transducer, 125A:

  • High Accuracy and Linearity: Delivers exceptional precision with a typical accuracy of ±0.5% and linearity of ±0.1%, ensuring reliable current measurement.
  • Wide Frequency Bandwidth: This device measures currents across a wide frequency range (DC to 150 kHz), making it suitable for various applications, including motor drives and power supplies.
  • Fast Response Time: The transducer offers a rapid response time of 0.5 microseconds, enabling real-time current monitoring for critical systems.
  • Excellent Temperature Stability: Operates effectively within a broad temperature range of -40°C to +85°C, maintaining consistent performance in diverse environments.
  • Easy PCB Mounting: Features a compact, through-hole design for convenient integration into printed circuit boards.

Broad Range Applications of LA125-P – LEM Current Transducer, 125A:

  • Industrial Automation: Current monitoring in AC and DC variable speed drives, servo motor drives, and battery-powered applications.
  • Power Electronics: Precise current measurement in Uninterruptible Power Supplies (UPS), Switched Mode Power Supplies (SMPS), and welding power supplies.
  • Renewable Energy Systems: Monitoring currents in solar inverters and wind turbine converters.
