MMBT3906_R2_00001- - TRANSISTOR DIS.200mA 40V PNP SOT23 GEN.SMT

MMBT3906_R2_00001-
brand logo

HT Part No. HT260624

Mfr. Part No. MMBT3906_R2_00001-

Manufacturer: PANJIT

Technical Documents:

9 - In Stock pcs
Price:
£ 0.27
Units Per Unit Prices
2 - 11999 £ 0.27
12000 + £ 0.23
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Manufacturer PANJIT
Mounting Type SMT
Package / Case SOT23
Transistor Type General Purpose
Channel PNP
Current 200mA
Current Temperature (IC) 25°C
Voltage (Collector-Emitter) 40V
Power Dissipation 225mW
Configuration Single
Applications General Purpose
Junction Temperature (Tj) 150°C
Operating Temperature -55°C~+150°C
Rohs ROHS
Packaging TAPE&REEL

More Information

The PANJIT MMBT3906_R2_00001- is a general-purpose, PNP bipolar junction transistor designed for surface-mount technology (SMT). It operates with a maximum current of 200mA and a voltage of 40V, packaged in the SOT-23 format.

Primary Functions of the PANJIT MMBT3906_R2_00001-, PNP Bipolar Junction Transistor

  • Switching: Controls the flow of current between the collector and emitter.
  • Amplification: Increases the strength of a weak signal.

Perks and Benefits of the PNP Bipolar Junction Transistor

  • Compact Size: Ideal for space-constrained applications due to SOT-23 packaging.
  • High Efficiency: Provides reliable performance with low power consumption.
  • Versatility: Suitable for various applications.

Where to Use the PANJIT MMBT3906_R2_00001-, PNP Bipolar Junction Transistor?

  • Signal Processing: Used in amplifiers and signal conditioning circuits.
  • Switching Circuits: Essential in switching applications for electronic devices.
  • General-Purpose Electronics: Fits into various consumer electronics and industrial devices.
