TEXAS LM336D-2-5, IC-336 VREF SHUNT 2.49V 8SOIC

LM336D-2-5
brand logo

HT Part No. HT192483

Mfr. Part No. LM336D-2-5

Manufacturer: TEXAS

Technical Documents:

1 - In Stock pcs
Price:
£ 0.95
Units Per Unit Prices
1 - 74 £ 0.95
75 + £ 0.86
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Features 2.5V Integrated Reference Circuit
Manufacturer TEXAS
Mounting Type SMT
Package / Case SOIC8
Reference Type Shunt
Output Type Fixed
Output Voltage 2.49V Min.
Input Voltage N/A
Supply Current 400uA (Cathode)
Tolerance ±4%
Operating Temperature 0°C~+70°C
Rohs ROHS
Packaging TUBE

More Information

The TEXAS LM336D-2-5 is a precision voltage reference IC designed to provide a stable 2.49V shunt reference. Encased in an 8-SOIC package, this component is perfect for applications requiring high accuracy and reliability. It operates as a temperature-compensated, two-terminal, bandgap reference diode, ensuring consistent performance over a wide range of temperatures and conditions.

Standout Features and Benefits of Using the TEXAS LM336D-2-5, Voltage Reference IC

  • Precision: High accuracy with a low temperature coefficient
  • Temperature Stability: Compensated for minimal drift
  • Operating Current: Low current operation
  • High Accuracy: Ensures precise voltage regulation and measurement
  • Temperature Stability: Reliable performance across various temperatures
  • Compact Design: Fits easily into space-constrained applications
  • Low Power Consumption: Efficient for battery-operated devices

Application Versatility of the TEXAS LM336D-2-5, Voltage Reference IC

  • Voltage Regulation: Utilised in power supply circuits for stable voltage output
  • Analogue-to-Digital Converters: Provides a stable reference voltage
  • Precision Measurement Devices: Ensures accuracy in test and measurement equipment
  • Data Acquisition Systems: Stable reference for reliable data
  • Portable Electronics: Ideal for devices requiring low power and high precision
