3296W-101-100R - TRIMPOT CERMET MULTI TURN VER.ADJ 100R 0.5W

3296W-101-100R
brand logo

HT Part No. HT235836

Mfr. Part No. 3296W-101-100R

Manufacturer: HONGXING

Technical Documents: Datasheet(datasheets)

451 - In Stock pcs
Price:
£ 0.22
Units Per Unit Price
1 - 49 £ 0.22
50 + £ 0.19
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Resistive Material Cermet
Width 4.85mm
Mounting Type THT
Termination Style Pc Pin
Keyword cermet trimpot, kombi trimpot, kombi kart trimpot, 3296 trimpot
Resistance Value 100 Ohms
KNOB Without Knob
Diameter N/A
Packaging TUBE
Manufacturer HONGXING
Series 3296
Power 0.50W
Adjustment Type Top Adjustment
Tolerance ±%10
Rohs ROHS
Temperature Coefficient ±100ppm/°C
Number of Turns Multi Turn
Length 9.50mm
Height 10.00mm

More Information

The HONGXING 3296W-101-100R is a Cermet Multi-Turn Trimpot designed for precise resistance adjustment in electronic circuits. This specific model offers a 100-ohm resistance with a 0.5W power rating and features vertical adjustment for ease of use in various applications. It is a variable resistor used to fine-tune circuit parameters. The HONGXING 3296W-101-100R model is a multi-turn trimmer, which allows for precise adjustments through multiple rotations of its screw.

Potential Benefits and Features of the Variable Resistor, Potentiometer

  • Precision: Multi-turn design enables accurate and fine adjustments.
  • Durability: Cermet material ensures long-lasting performance.
  • Ease of use: Vertical adjustment is convenient for space-constrained applications.
  • Reliability: High-quality construction offers consistent performance over time.

Application Information

  • Calibration: Used in the calibration of circuits for accurate performance.
  • Tuning: Ideal for tuning oscillators, sensors, and other precision components.
  • Feedback Control: Common feedback circuits to set and adjust reference points.
  • Prototyping: Useful in the development and testing phases of electronic designs for tweaking parameters.
