IXYS MCC161-22IO1, THYRISTOR MOD.DUAL 165A 2200V Y4-M6 CHASSIS

MCC161-22IO1
brand logo

HT Part No. HT257248

Mfr. Part No. MCC161-22IO1

Manufacturer: IXYS

Technical Documents:

15 - In Stock pcs
Price:
£ 146.32
Units Per Unit Price
1 - 5 £ 146.32
6 + £ 139.35
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Current Temperature (IC) 85°C
Forward Drop (VT) 1.14V
Junction Temperature (Tj) N/A
Current Hold (IH) 200mA
Gate Trigger (Vgt) 2V
Applications N/A
Manufacturer IXYS
RMS On State (ITrms) 300A (2x300A)
Tq 150us
Operating Temperature -40°C~+100°C
Series Thyristor Phase Control
Voltage (VRRM) 2.2kV
Trr N/A
Rohs ROHS
Mounting Type Chassis
Package / Case Y4-M6
Current On State (ITav) 165A (2x165A)
Power Dissipation 645W
Configuration Dual
Packaging BOX

More Information

The IXYS MCC161-22IO1 is a powerful thyristor module designed for robust industrial applications. It combines high current handling capabilities with efficient performance. This dual thyristor module is rated at 165A and 2200V and encapsulated in a Y4-M6 chassis configuration. It stands out for its reliability, efficiency, and suitability for heavy-duty industrial applications requiring robust power handling capabilities.

Unique Features and Benefits of Using the IXYS MCC161-22IO1, Thyristor Module

  • Dual thyristor module design.
  • Voltage rating of 2200V ensures reliable operation in high-voltage environments.
  • Y4-M6 chassis configuration provides robust mechanical support and thermal management.
  • Enables efficient power control and switching in industrial equipment.
  • Reliable performance under high currents and voltages, suitable for demanding environments.
  • Compact design optimises space utilisation in equipment layouts.

Application Areas of the Thyristor Module

  • Industrial Motor Drives.
  • Power Supplies and Converters.
  • Welding Equipment.
  • High-power switching applications where precise control and reliability are critical.
