IXYS CMA50E1600HB, THYRISTOR DIS.SINGLE 50A 1600V TO247-3 THT

CMA50E1600HB
brand logo

HT Part No. HT256345

Mfr. Part No. CMA50E1600HB

Manufacturer: IXYS

Technical Documents: Datasheet(datasheets)

21194 - In Stock pcs
Price:
£ 2.38
Units Per Unit Price
1 - 29 £ 2.38
30 + £ 2.16
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Series Thyristor Phase Control
RMS On State (ITrms) 79A
Configuration Single
Packaging TUBE
Current On State (ITav) 50A
Current Temperature (IC) 110°C
Current Hold (IH) 100mA
Trr N/A
Forward Drop (VT) 1.3V
Tq 150us
Operating Temperature -40°C~+125°C
Rohs ROHS
Manufacturer IXYS
Mounting Type THT
Gate Trigger (Vgt) 1.5V
Applications N/A
Junction Temperature (Tj) N/A
Package / Case TO247-3
Voltage (VRRM) 1.6kV
Power Dissipation 310W

More Information

The IXYS CMA50E1600HB is a single thyristor with a current rating of 50A and a voltage rating of 1600V, housed in a TO-247-3 package designed for through-hole technology (THT) mounting. It is designed to efficiently control high power in various electronic circuits.

Unique Advantages of Using the IXYS CMA50E1600HB, Single Thyristor

  • Mounting Type: Through-Hole Technology (THT)
  • Robust Design: High surge capability
  • Control: Efficient switching capabilities
  • High Performance: Manages high power levels efficiently
  • Durability: Robust design ensures long operational life
  • Versatile: Suitable for various high-power applications
  • Cost-Effective: Reduces the need for multiple components

Application Areas

  • Power Supplies: Regulation and rectification
  • Motor Control: Efficiently controls motor speeds and torque
  • Industrial Equipment: Utilised in industrial power control systems
  • Lighting Systems: Manages high-intensity discharge lamps
  • HVAC Systems: Controls heating, ventilation, and air conditioning systems
