IXYS CS22-12IO1M, THYRISTOR DIS.SINGLE 16A 1200V TO-220FP THT

CS22-12IO1M
brand logo

HT Part No. HT256339

Mfr. Part No. CS22-12IO1M

Manufacturer: IXYS

Technical Documents: Datasheet(datasheets)

397 - In Stock pcs
Price:
£ 2.51
Units Per Unit Price
1 - 49 £ 2.51
50 + £ 2.28
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Power Dissipation 50W
Configuration Single
Series Thyristor Phase Control
Tq 150us
Applications N/A
Junction Temperature (Tj) N/A
Current Temperature (IC) 25°C
Current Hold (IH) 60mA
Voltage (VRRM) 1.2kV
Packaging TUBE
Mounting Type THT
Package / Case TO220FP
Gate Trigger (Vgt) 1.3V
Trr N/A
Manufacturer IXYS
Current On State (ITav) 16A
RMS On State (ITrms) 25A
Forward Drop (VT) 1.3V
Operating Temperature -55°C~+125°C
Rohs ROHS

More Information

The IXYS CS22-12IO1M is a high-performance, single thyristor designed for various electrical and electronic applications. It offers a maximum current capacity of 16A and can handle up to 1200V, housed in a TO-220FP package. This through-hole technology (THT) component is known for its reliability and efficiency in controlling high-power devices.

Unique Benefits of the IXYS CS22-12IO1M, Single Thyristor

  • Robust Design: Suitable for high-power applications
  • Efficient Power Control: Manages high currents and voltages effectively
  • Enhanced Reliability: Durable design ensures long-term operation
  • Versatile Use: Suitable for various industrial applications
  • Compact Size: Easy integration into existing systems

Where Can I Use the IXYS CS22-12IO1M Single Thyristor?

  • Power Supply Regulation: Ensures stable power output
  • Motor Control: Efficiently manages motor operations
  • Lighting Systems: Ideal for controlling high-intensity lighting
  • Industrial Equipment: Used in machinery requiring precise power control
