IXYS CLA50E1200HB, THYRISTOR DIS.SINGLE 50A 1200V TO247-3 THT

CLA50E1200HB
brand logo

HT Part No. HT256335

Mfr. Part No. CLA50E1200HB

Manufacturer: IXYS

Technical Documents: Datasheet(datasheets)

57327 - In Stock pcs
Price:
£ 2.10
Units Per Unit Price
1 - 29 £ 2.10
30 + £ 1.92
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Configuration Single
Manufacturer IXYS
Junction Temperature (Tj) N/A
Package / Case TO247-3
Current Temperature (IC) 125°C
Voltage (VRRM) 1.2kV
Applications N/A
Operating Temperature -40°C~+150°C
Series Thyristor Phase Control
Mounting Type THT
Current On State (ITav) 50A
RMS On State (ITrms) 79A
Gate Trigger (Vgt) 1.5V
Forward Drop (VT) 1.32V
Rohs ROHS
Current Hold (IH) 100mA
Power Dissipation 500W
Trr N/A
Tq 200us
Packaging TUBE

More Information

The IXYS CLA50E1200HB is a single thyristor designed for high-current and high-voltage applications. It features a 50A current rating and a 1200V voltage rating, housed in a TO247-3 through-hole package, making it suitable for robust and reliable electronic and electrical applications. It is ideal for demanding applications requiring high current and voltage handling, offering reliable performance and easy circuit integration.

Potential Advantages of Using the IXYS CLA50E1200HB, Single Thyristor

  • Reliable performance in high-power applications
  • Efficient heat dissipation due to the TO247-3 package design
  • Easy integration into existing circuits with through-hole technology
  • Low gate trigger current ensures efficient switching
  • Robust construction for long-lasting operation

Application Versatility of the Single Thyristor

  • Motor Control and Drives
  • Power Supplies
  • Industrial Heating and Lighting
  • AC And DC Switching
  • Phase Control Applications
