HT Part No. HT23374
Mfr. Part No. MCC312-16IO1
Manufacturer: IXYS
Technical Documents: MCC312-16io1 Datasheet-e59b3fdd(datasheets)
| Product Attributes | |
|---|---|
| Rated Average On-State Current | 320A |
| Thyristor Type | SCR Module |
| Package Type | Y1 CU |
| Repetitive Peak Reverse Voltage | 1600V |
| Surge Current Rating | 10.1kA |
| Mounting Type | Panel Mount |
| Maximum Gate Trigger Current | 150mA |
| Maximum Gate Trigger Voltage | 2V |
| Maximum Holding Current | 150mA |
| Pin Count | 7 |
| Dimensions | 115 x 50 x 49mm |
| Repetitive Peak Forward Blocking Voltage | 1600V |
| Minimum Operating Temperature | -40 °C |
| Maximum Operating Temperature | +140 °C |
| Repetitive Peak Off-State Current | 40mA |
| Peak On-State Voltage | 1.32V |
