IXYS MCD225-14IO1, THYRISTOR DIODE MOD.DUAL 221A 1400V Y1-CU CHASSIS

MCD225-14IO1
brand logo

HT Part No. HT190641

Mfr. Part No. MCD225-14IO1

Manufacturer: IXYS

Technical Documents:

171 - In Stock pcs
Price:
£ 84.93
Units Per Unit Price
1 - 2 £ 84.93
3 + £ 79.38
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Current Temperature (IC) 85°C
Tq 200us
Current On State (ITav) 220A (2x220A)
Forward Drop (VT) 1.04V
Power Dissipation N/A
Configuration Dual
Manufacturer IXYS
Junction Temperature (Tj) N/A
Operating Temperature -40°C~+130°C
Rohs ROHS
Series Thyristor Phase Control
RMS On State (ITrms) 400A (2x400A)
Current Hold (IH) 150mA
Voltage (VRRM) 1.4kV
Trr N/A
Mounting Type Chassis
Package / Case Y1-CU
Gate Trigger (Vgt) 2V
Applications N/A
Packaging BOX

More Information

The IXYS MCD225-14IO1 is a high-power thyristor diode module designed for efficient control and rectification in power electronics. It features dual thyristors capable of handling 221A and 1400V, making it suitable for high-voltage, high-current applications. It ensures robust and efficient performance, making it a preferred choice in high-power industrial and commercial applications.

Special Features of the IXYS MCD225-14IO1, Thyristor Diode

  • Y1-CU chassis for efficient heat dissipation
  • Robust construction for high reliability
  • High current and voltage handling for demanding applications
  • Efficient thermal management due to the Y1-CU chassis
  • Enhanced reliability and longevity
  • Ideal for high-power control and rectification tasks

Where Can I Use the IXYS MCD225-14IO1, Thyristor Diode?

  • Power Supplies
  • Motor Control
  • Welding Equipment
  • Uninterruptible Power Supplies (UPS)
  • High-voltage direct Current (HVDC) Transmission Systems
