IXYS MCD220-16IO1, THYRISTOR DIODE MOD.DUAL 250A 1600V Y2-DCB CHASSIS

MCD220-16IO1
brand logo

HT Part No. HT190636

Mfr. Part No. MCD220-16IO1

Manufacturer: IXYS

Technical Documents: Datasheet(datasheets)

6 - In Stock pcs
Price:
£ 43.01
Units Per Unit Price
1 - 1 £ 43.01
2 + £ 40.20
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Operating Temperature -40°C~+140°C
Packaging BOX
Power Dissipation N/A
Tq 200us
Applications N/A
Rohs ROHS
Current Hold (IH) 150mA
Junction Temperature (Tj) N/A
Series Thyristor Phase Control
Package / Case Y2-DCB
Current Temperature (IC) 85°C
Forward Drop (VT) 1.53V
Configuration Dual
Manufacturer IXYS
Mounting Type Chassis
Current On State (ITav) 250A (2x250A)
RMS On State (ITrms) 400A (2x400A)
Voltage (VRRM) 1.6kV
Gate Trigger (Vgt) 2V
Trr N/A

More Information

The IXYS MCD220-16IO1 is a dual thyristor-diode module designed for high-power applications. It can handle up to 250A of current at 1600V and combines reliability, efficiency, and robust construction, making it ideal for critical power management applications where performance and durability are paramount.

Advanced Attributes of the IXYS MCD220-16IO1, Dual Thyristor-Diode

  • Dual functionality with both thyristor and diode modules integrated.
  • High current handling capacity of 250A.
  • Y2-DCB chassis design for effective thermal management and mechanical robustness.
  • Low forward voltage drop for efficient energy management.

Benefit for You

  • Enables efficient power control and switching in industrial applications.
  • Compact design saves space and simplifies integration into systems.
  • Reliable performance under high temperatures and harsh environments.
  • Reduces losses and enhances energy efficiency in power electronics.

Typical Uses of the IXYS MCD220-16IO1, Dual Thyristor-Diode

  • Industrial Motor Drives
  • Power Supplies and Inverters
  • Welding Equipment
  • Renewable Energy Systems
