IXYS VCD105-08IO7, THYRISTOR DIODE MOD.DUAL 105A 800V ECOPAC2 CHASSIS

VCD105-08IO7
brand logo

HT Part No. HT190628

Mfr. Part No. VCD105-08IO7

Manufacturer: IXYS

Technical Documents: Datasheet(datasheets)

5 - In Stock pcs
Price:
£ 34.59
Units Per Unit Price
1 - 24 £ 34.59
25 + £ 32.33
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Applications N/A
Current Hold (IH) 200mA
Gate Trigger (Vgt) 1.5V
Operating Temperature -40°C~+125°C
RMS On State (ITrms) 180A (2x180A)
Voltage (VRRM) 800V
Configuration Dual
Rohs ROHS
Packaging BOX
Package / Case ECO-PAC2
Current On State (ITav) 105A (2x105A)
Current Temperature (IC) 85°C
Trr N/A
Junction Temperature (Tj) N/A
Manufacturer IXYS
Series Thyristor Phase Control
Mounting Type Chassis
Forward Drop (VT) 1.5V
Power Dissipation N/A
Tq N/A

More Information

The IXYS VCD105-08IO7 is a dual thyristor-diode module designed for high-current and high-voltage applications. It is encapsulated in the ECOPAC2 chassis for efficient thermal management and durability. This module offers robust performance and reliability, making it perfect for various high-power electronic applications.

Potential Advantages of Using the IXYS VCD105-08IO7 Dual Thyristor-Diode Module

  • Enables efficient power switching and control.
  • High reliability and durability due to the ECOPAC2 encapsulation.
  • Simplified installation and maintenance with screw terminals.
  • Capable of handling high currents and voltages, ideal for demanding applications.

Typical Uses of the IXYS VCD105-08IO7, Dual Thyristor-Diode Module

  • Industrial Motor Drives and Controls
  • Power Supplies and UPS Systems
  • Welding Equipment and Industrial Heating Systems
  • Wind and Solar Inverters
  • Electric Vehicle Charging Infrastructure

Unique Features of the Thyristor Module Include

  • Dual module combining thyristor and diode functionality.
  • Screw terminals for secure electrical connections.
  • Compact design suitable for industrial and commercial installations.
