IXYS MCD56-08IO8B, THYRISTOR DIODE MOD.DUAL 60A 800V TO240AA CHASSIS

IXYS MCD56-08IO8B, THYRISTOR DIODE MOD.DUAL 60A 800V TO240AA CHASSIS
MCD56-08IO8B
brand logo

HT Part No. HT190623

Mfr. Part No. MCD56-08IO8B

Manufacturer: IXYS

Technical Documents:

1 - In Stock pcs
Price:
£ 24.70
Units Per Unit Prices
1 - 35 £ 24.70
36 + £ 23.08
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Packaging BOX
Manufacturer IXYS
Forward Drop (VT) 1.26V
Tq 150us
Gate Trigger (Vgt) 1.5V
Power Dissipation 222W
Applications N/A
Package / Case TO240AA
Current On State (ITav) 60A (2x60A)
RMS On State (ITrms) 94A (2x94A)
Current Temperature (IC) 85°C
Configuration Dual
Operating Temperature -40°C~+100°C
Series Thyristor Phase Control
Mounting Type Chassis
Current Hold (IH) 200mA
Voltage (VRRM) 800V
Trr N/A
Junction Temperature (Tj) N/A
Rohs ROHS

More Information

The IXYS MCD56-08IO8B is a dual thyristor diode module rated at 60A and 800V in a TO-240AA chassis configuration. It combines robust construction with high performance, making it ideal for demanding applications requiring efficient power switching and control.

Unique Advantages of Using the IXYS MCD56-08IO8B, Dual Thyristor Diode

  • Dual thyristor-diode design for efficient power control.
  • Isolated baseplate for enhanced reliability and ease of mounting.
  • Reliable switching and control of high-power loads.
  • Compact design suitable for space-constrained applications.
  • Excellent thermal performance and durability.
  • Simplified installation and maintenance.

Usage Information of the IXYS MCD56-08IO8B, Dual Thyristor Diode

  • Industrial Motor Drives and Controls
  • Power Supplies and Inverters
  • Welding Equipment
  • Renewable Energy Systems
