IXYS WESTCODE R1178NC14E-U9900, THYRISTOR DISC FAST REC.SINGLE 1178A 1400V CHASSIS

R1178NC14E-U9900
brand logo

HT Part No. HT190114

Mfr. Part No. R1178NC14E-U9900

Manufacturer: IXYS WESTCODE

Technical Documents: Datasheet(datasheets)

34 - In Stock pcs
Price:
£ 1019.14
Units Per Unit Price
1 - 5 £ 1019.14
6 + £ 999.15
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Current Hold (IH) 1A
Operating Temperature -40°C~+125°C
Package / Case Disc (W11)
Voltage (VRRM) 1.4kV
Forward Drop (VT) 2.2V
Manufacturer IXYS WESTCODE
Series Distributed Gate Fast Thyristor
Tq 25us
Packaging BOX
Gate Trigger (Vgt) 3V
Power Dissipation N/A
Configuration Single
Applications N/A
Rohs NON ROHS
Mounting Type Chassis
Current On State (ITav) 1.178kA
RMS On State (ITrms) 2.395kA
Current Temperature (IC) 55°C
Trr 3.7us
Junction Temperature (Tj) N/A

More Information

The IXYS WESTCODE R1178NC14E-U9900 is a high-performance thyristor uniquely designed for fast recovery applications. It stands out as a single, disc-type component with a maximum current rating of 1178A and a voltage rating of 1400V, making it a standout choice for high-power and high-voltage applications.

Key Attributes of the IXYS WESTCODE R1178NC14E-U9900, Thyristor

  • Fast recovery time
  • Disc-type chassis mounting
  • Single thyristor design

Benefits for You

  • Efficient handling of high-power loads
  • Reliable performance in demanding environments
  • Enhanced thermal management due to disc-type design
  • Reduced downtime and maintenance with robust construction
  • Versatility in various high-power applications

Usage Information of the IXYS WESTCODE R1178NC14E-U9900, Thyristor

This thyristor's robust design and high ratings make it ideal for industries requiring efficient and reliable power management solutions, such as:

  • Power Conversion Systems
  • Motor Drives and Controls
  • High-Voltage DC Transmission
  • Induction Heating Systems
  • Uninterruptible Power Supplies (UPS)
