N3029ZC240-U9900 - THYRISTOR DISC SINGLE 3029A 2400V CHASSIS

N3029ZC240-U9900
brand logo

HT Part No. HT190105

Mfr. Part No. N3029ZC240-U9900

Manufacturer: IXYS WESTCODE

Technical Documents: Datasheet(datasheets)

18 - In Stock pcs
Price:
£ 845.38
Units Per Unit Price
1 - 5 £ 845.38
6 + £ 828.81
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Mounting Type Chassis
Configuration Single
Current Temperature (IC) 55°C
Forward Drop (VT) 1.5V
Tq 250us
Package / Case Disc (W13)
Current On State (ITav) 3.029kA
Current Hold (IH) 1A
Applications N/A
Manufacturer IXYS WESTCODE
RMS On State (ITrms) 5.967kA
Gate Trigger (Vgt) 3V
Rohs NON ROHS
Packaging BOX
Series Thyristor Phase Control
Voltage (VRRM) 2.4kV
Power Dissipation N/A
Trr 37us
Junction Temperature (Tj) N/A
Operating Temperature -40°C~+125°C

More Information

The IXYS WESTCODE 530172 is a high-performance semiconductor device designed for efficient power control and switching applications. Thyristors, also known as silicon-controlled rectifiers (SCRs), are essential components in power electronics, allowing for precise control of electrical power in various systems. This disc-type thyristor, designated as W13, offers superior thermal and electrical performance, making it an ideal choice for demanding industrial applications. A thyristor disc, specifically the IXYS WESTCODE 530172, is utilised for high-efficiency power control and switching in electrical systems.

Benefits

  • High current handling capacity
  • Excellent thermal performance
  • Robust and reliable operation
  • Low on-state voltage drop
  • High surge current capability

Applications

This thyristor disc is designed to meet the rigorous demands of modern power electronics, ensuring efficient and reliable operation in various applications, such as:

  • Power Conversion Systems
  • Motor Control Circuits
  • Industrial Heating and Welding
  • Uninterruptible Power Supplies (UPS)
  • AC And DC Drives
