R0964LC12D-U9900 - THYRISTOR DISC FAST REC.SINGLE 964A 1200V CHASSIS

R0964LC12D-U9900
brand logo

HT Part No. HT190101

Mfr. Part No. R0964LC12D-U9900

Manufacturer: IXYS WESTCODE

Technical Documents: Datasheet(datasheets)

3 - In Stock pcs
Price:
£ 594.14
Units Per Unit Price
1 - 5 £ 594.14
6 + £ 565.85
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Current Temperature (IC) 55°C
Forward Drop (VT) 1.96V
Configuration Single
Junction Temperature (Tj) N/A
Operating Temperature -40°C~+125°C
Current On State (ITav) 964A
Rohs NON ROHS
Packaging BOX
Manufacturer IXYS WESTCODE
Series Distributed Gate Fast Thyristor
Voltage (VRRM) 1.2kV
Trr 2.15us
Mounting Type Chassis
Package / Case Disc (W10)
RMS On State (ITrms) 1.971kA
Current Hold (IH) 1A
Gate Trigger (Vgt) 3V
Power Dissipation N/A
Tq 20us
Applications N/A

More Information

The R0964LC12D-U9900 is a high-performance, chassis-mount thyristor disc known for its robust design and reliable operation. It is a single thyristor device rated at 964A and 1200V, making it suitable for applications that require high current and voltage capabilities. This component is used extensively in power control and conversion applications due to its capability to handle significant power loads efficiently and with minimal loss.

Special Features & Benefits of R0964LC12D-U9900 Single Thyristor Disc:

  • High Current Rating: Capable of handling up to 964A, allowing it to support heavy-duty applications.
  • High Voltage Rating: With a voltage rating of 1200V, it is ideal for high-voltage applications, ensuring safe and reliable operation under demanding conditions.
  • Robust Design: The chassis-mount configuration provides excellent thermal management and mechanical stability, enhancing the device's overall durability and lifespan.
  • Efficient Power Control: This system offers precise control over high-power loads, improving the efficiency and performance of power systems.
  • Reliability: Designed to operate reliably in harsh environments, ensuring consistent performance and reduced maintenance needs.
  • Thermal Management: Excellent thermal conductivity effectively manages heat dissipation, ensuring optimal performance even in high-temperature conditions.

Typical Applications of R0964LC12D-U9900 Single Thyristor Disc, Chassis-Mount:

  • Power Converters
  • Motor Drives
  • HVAC Systems
  • Uninterruptible Power Supplies (UPS)
  • Renewable Energy Systems
  • Welding Equipment.
