PANASONIC COMP. EVQ-PNF04M, SWITCH TACT SPST-NO TOP ACTUATED SURFACE MOUNT

EVQ-PNF04M
brand logo

HT Part No. HT236308

Mfr. Part No. EVQ-PNF04M

Manufacturer: PANASONIC COMP.

Technical Documents: Datasheet(datasheets)

10520 - In Stock pcs
Price:
£ 0.57
Units Per Unit Price
1 - 2499 £ 0.57
2500 + £ 0.50
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Manufacturer PANASONIC COMP.
Illumination Type/Color None
Series EVQPN
Voltage Rating (AC) None
Mounting Type SMT V/T
Voltage Rating (DC) 12V
Operating Force 160gF
Washable N/A
Outline 6.00x3.50mm
Circuit SPST-NO
Actuator Type Rectangular
Actuator COLOR N/A
Keyword butonlu siviç
Actuator Height off PCB, From Pins 4.30mm
Current Rating (AC) None
Current Rating (DC) 50mA
Operating Temperature -30°C~+85°C
Rohs ROHS
Packaging TAPE&REEL

More Information

The Panasonic COMP. EVQ-PNF04M is a compact and reliable tactile switch designed for surface mount applications. This SPST-NO (Single Pole Single Throw - Normally Open) switch features a top-actuated design, providing a tactile feedback mechanism for user interaction. Known for its durability and consistent performance, the EVQ-PNF04M is a versatile component suitable for a wide range of electronic devices.

Salient Features and Benefits of the Panasonic COMP. EVQ-PNF04M, Tactile Switch

  • Compact surface mount design
  • Top-actuated for user convenience
  • Durable and reliable performance
  • Space-saving solution for PCB assemblies
  • Improved user experience with tactile feedback
  • Simple on/off switching functionality
  • Consistent performance over a long lifespan

Usage Information of the Panasonic COMP. EVQ-PNF04M, Tactile Switch

  • Consumer electronics
  • Automotive controls
  • Industrial equipment
  • Medical devices
