CORE MASTER SRI1209-220M, INDUCTOR POWER 22UH 12X12MM SMD

SRI1209-220M
brand logo

HT Part No. HT194982

Mfr. Part No. SRI1209-220M

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

543 - In Stock pcs
Price:
£ 0.44
Units Per Unit Price
1 - 299 £ 0.44
300 + £ 0.39
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Current - Saturation (Isat) N/A
Applications General Purpose
Length 12.00mm
Operation Temperature N/A
Package / Case Non Standard
Inductance 22uH
Width 12.00mm
Rohs ROHS
Shielding Shielded
Current Rating 7.5A
Tolerance ±20%
Pitch None
Technology Power
Diameter N/A
Height 10.00mm
Packaging TAPE&REEL
Manufacturer CORE MASTER
Series SRI
Mounting Type SMT
DC Resistance (DCR) 40m Ohms

More Information

The CORE MASTER SRI1209-220M is a high-performance SMD power inductor designed for demanding electronic applications. With a robust inductance of 22µH and a compact 12x12mm size, this inductor is ideal for space-constrained environments while offering exceptional performance. It features a low DC resistance, ensuring minimal power loss and improved efficiency in power supply circuits. The SRI1209-220M is constructed with high-quality materials that provide excellent thermal stability and reliability, making it suitable for various temperatures and operating conditions. Its shielded design minimises electromagnetic interference, enhancing overall circuit performance.

Possible Advantages of the CORE MASTER SRI1209-220M, SMD Power Inductor

  • High thermal stability and reliability
  • Shielded design to minimise EMI
  • Enhanced efficiency with minimal power loss
  • Space-saving design for compact applications
  • Reliable performance across various temperatures

Application Information

  • Power Supply Circuits
  • DC-DC Converters
  • Automotive Electronics
  • Consumer Electronics
  • Telecommunications Equipment
