COILCRAFT XAL6060-223MEC, INDUCTOR FIXED 22uH %20 5A 63mOhms AECQ

XAL6060-223MEC
brand logo

HT Part No. HT194980

Mfr. Part No. XAL6060-223MEC

Manufacturer: COILCRAFT

Technical Documents: Datasheet(datasheets)

282 - In Stock pcs
Price:
£ 2.45
Units Per Unit Price
1 - 249 £ 2.45
250 + £ 2.22
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Manufacturer COILCRAFT
Pitch None
Rohs ROHS
Shielding Shielded
Inductance 22uH
Tolerance ±20%
Technology Power
DC Resistance (DCR) 55.12m Ohms
Applications Automotive(AEC-Q200)
Package / Case Non Standard
Current Rating 3.6A
Diameter N/A
Width 6.36mm
Series XAL
Mounting Type SMT
Current - Saturation (Isat) N/A
Length 6.56mm
Height 6.10mm
Operation Temperature -40°C ~ +125°C
Packaging TAPE&REEL

More Information

The COILCRAFT XAL6060-223MEC is a high-performance fixed inductor with a 22µH inductance, 20% tolerance, a current rating of 5A, and a low DC resistance of 63mOhms. It meets AEC-Q200 automotive standards, making it suitable for automotive and other high-reliability applications.

Unique Advantages of Using the COILCRAFT XAL6060-223MEC, Fixed Inductor

  • Shielded construction for low EMI
  • High current handling capability
  • Low DC resistance for efficient performance
  • Compliance with automotive standards ensures reliability
  • Compact size saves space on the PCB
  • Shielding minimises electromagnetic interference

Versatile Uses of the COILCRAFT XAL6060-223MEC, Fixed Inductor

The COILCRAFT XAL6060-223MEC inductor's robust design and high efficiency make it an excellent choice for demanding applications, including:

  • Automotive Electronics
  • DC-DC Converters
  • Power Supplies
  • Industrial Controls
  • Telecommunications Equipment
  • Consumer Electronics
