CORE MASTER WHI0402-15NJ-N, INDUCTOR FIXED 0402 15NH SMD

WHI0402-15NJ-N
brand logo

HT Part No. HT194972

Mfr. Part No. WHI0402-15NJ-N

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

10334 - In Stock pcs
Price:
£ 0.12
Units Per Unit Price
1 - 3999 £ 0.12
4000 + £ 0.10
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Inductance 15nH
Length 1.19mm
Width 0.64mm
Height 0.66mm
Rohs ROHS
Packaging TAPE&REEL
Mounting Type SMT
Technology Wire Wound
Tolerance ±5%
Operation Temperature N/A
Package / Case 0402 (1005 Metric)
Pitch None
Current Rating 560mA
Diameter N/A
Manufacturer CORE MASTER
Series WHI
Shielding Unshielded
Current - Saturation (Isat) N/A
DC Resistance (DCR) 170m Ohms
Applications General Purpose

More Information

The CORE MASTER WHI0402-15NJ-N is a high-performance, fixed inductor designed for compact SMD (Surface-Mount Device) applications. With a size of just 0402 and an inductance value of 15nH, this component is perfect for high-frequency circuits where space is at a premium. Its small footprint and efficient design make it ideal for use in modern electronic devices that demand reliability and high-speed performance.

What Are the Unique Features and Benefits of the CORE MASTER WHI0402-15NJ-N, Power Inductor?

  • Surface-mount design for easy integration
  • High-quality construction for reliable performance
  • Space-saving design ideal for miniaturized circuits
  • Excellent performance in high-speed and high-frequency applications
  • Reliable operation with low series resistance

Application Areas of the CORE MASTER WHI0402-15NJ-N, Power Inductor

  • RF Circuits
  • Communication Devices
  • Mobile Electronics
  • High-Speed Data Processing Systems
