CHILISIN SCD0502T-220M-N, INDUCTOR POWER 22uH 5.8x5.3x2.5 SMD

CHILISIN SCD0502T-220M-N, INDUCTOR POWER 22uH 5.8x5.3x2.5 SMD
SCD0502T-220M-N
brand logo

HT Part No. HT194954

Mfr. Part No. SCD0502T-220M-N

Manufacturer: CHILISIN

Technical Documents:

181 - In Stock pcs
Price:
£ 0.15
Units Per Unit Prices
1 - 1999 £ 0.15
2000 + £ 0.13
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Series SCD
Package / Case Non Standard
Inductance 22uH
Width 5.20mm
Operation Temperature -40°C ~ +105°C
Pitch None
DC Resistance (DCR) 350m Ohms
Applications General Purpose
Diameter N/A
Mounting Type SMT
Current - Saturation (Isat) N/A
Length 5.80mm
Rohs ROHS
Manufacturer CHILISIN
Technology Power
Shielding Unshielded
Current Rating 1A
Tolerance ±20%
Height 2.50mm
Packaging TAPE&REEL

More Information

The CHILISIN SCD0502T-220M-N is a high-performance surface-mount device (SMD) inductor designed for power applications. It features a 22uH inductance, encapsulated in a compact 5.8x5.3x2.5mm package. This inductor is engineered to deliver low DCR (DC resistance) and high efficiency, making it an ideal choice for power management solutions. It offers excellent thermal stability and can handle various temperatures, guaranteeing reliable operation in different environments.

Potential Advantages of the CHILISIN SCD0502T-220M-N, Power Inductor SMD

  • Low DCR for high-efficiency
  • High thermal stability
  • Compact size saves PCB space
  • Efficient power conversion
  • Reliable performance across temperature ranges

The CHILISIN SCD0502T-220M-N, Power Inductor SMD: Wide Application Range

  • Power Supply Circuits
  • DC-DC Converters
  • EMI Filtering
  • Automotive Electronics
