SUMIDA CDRH4D28NP-220NC, INDUCTOR POWER 22uHX5X5X3mm SMD

CDRH4D28NP-220NC
brand logo

HT Part No. HT194950

Mfr. Part No. CDRH4D28NP-220NC

Manufacturer: SUMIDA

Technical Documents: Datasheet(datasheets)

4 - In Stock pcs
Price:
£ 2.47
Units Per Unit Price
1 - 1999 £ 2.47
2000 + £ 2.25
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Manufacturer SUMIDA
Pitch None
Mounting Type SMT
Inductance 22uH
Tolerance ±30%
Length 5.00mm
Shielding Shielded
Current Rating 700mA
Applications General Purpose
Series CDRH
Width 5.00mm
Operation Temperature -40°C ~ +100°C
Packaging TAPE&REEL
Package / Case Non Standard
Technology N/A
Current - Saturation (Isat) N/A
DC Resistance (DCR) 235m Ohms
Diameter N/A
Height 3.00mm
Rohs ROHS

More Information

The SUMIDA CDRH4D28NP-220NC is a power inductor measuring 5x5x3mm designed for surface-mount applications. Its 22µH inductance value makes it suitable for various electronic circuits requiring energy storage and filtering. It features a ferrite core, which enhances its efficiency by minimising core losses. The SMD (Surface Mount Device) design allows for easy integration into compact electronic assemblies, supporting space-saving designs.

Significant Advantages of the SUMIDA CDRH4D28NP-220NC, Power Inductor

  • High efficiency due to low core losses
  • Compact size, ideal for space-constrained applications
  • Easy to integrate into existing circuits with SMD design
  • Reliable performance in various temperature conditions

Usage Information of the SUMIDA CDRH4D28NP-220NC, Power Inductor

The CDRH4D28NP-220NC inductor is a versatile component, essential for optimising power efficiency and stability in electronic systems, including:

  • Power Supply Circuits
  • DC-DC Converters
  • Noise Filtering in Electronic Devices
  • Power Management in Portable Electronics
