CORE MASTER SRI0704-220M, INDUCTOR POWER 22UH 7.3X7.3X4.5MM SMD

SRI0704-220M
brand logo

HT Part No. HT194949

Mfr. Part No. SRI0704-220M

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

422 - In Stock pcs
Price:
£ 0.25
Units Per Unit Price
1 - 999 £ 0.25
1000 + £ 0.22
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Diameter N/A
Height 4.50mm
Inductance 22uH
Length 7.30mm
Rohs ROHS
Current Rating 1.95A
Tolerance ±20%
Width 7.30mm
Mounting Type SMT
Package / Case Non Standard
Technology Power
Current - Saturation (Isat) N/A
Manufacturer CORE MASTER
Series SRI
Pitch None
Shielding Shielded
DC Resistance (DCR) 110m Ohms
Applications General Purpose
Operation Temperature N/A
Packaging TAPE&REEL

More Information

The CORE MASTER SRI0704-220M is a surface-mount device (SMD) power inductor designed for high-efficiency energy storage and filtering applications. It has an inductance of 22μH and is compact, measuring 7.3 x 7.3 x 4.5 mm. This inductor is constructed using high-quality materials to ensure low DC resistance and high saturation current, making it suitable for power supply circuits and DC-DC converters.

Key Features and Benefits of Using the CORE MASTER SRI0704-220M, Power Inductor

  • Low DC resistance: Minimises energy loss
  • High saturation current: Ensures stable performance under load
  • Efficient energy storage: Ideal for power-sensitive applications
  • Compact size: Saves space on circuit boards
  • Reliable performance: Suitable for high-frequency applications

Application Areas of the CORE MASTER SRI0704-220M, Power Inductor

  • Power Supply Circuits
  • DC-DC Converters
  • Noise Filtering in Electronic Devices
  • Energy Storage in Renewable Energy Systems
