CORE MASTER FPI0504-680M, INDUCTOR POWER 68UH 5.2X5.8X4.5MM SMD

FPI0504-680M
brand logo

HT Part No. HT194930

Mfr. Part No. FPI0504-680M

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 0.10
Units Per Unit Price
1 - 1499 £ 0.10
1500 + £ 0.089
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Rohs ROHS
Diameter N/A
Operation Temperature N/A
Series FPI
Pitch None
Applications General Purpose
Manufacturer CORE MASTER
Package / Case Non Standard
Current - Saturation (Isat) N/A
Tolerance ±20%
DC Resistance (DCR) 460m Ohms
Width 5.20mm
Mounting Type SMT
Technology Power
Shielding Unshielded
Inductance 68uH
Current Rating 850mA
Length 5.80mm
Height 4.50mm
Packaging TAPE&REEL

More Information

The CORE MASTER FPI0504-680M is a high-performance power inductor designed for compact, high-efficiency applications. With its dimensions of 5.2 x 5.8 x 4.5 mm, this SMD (Surface Mount Device) inductor offers a compact layout without compromising performance. It features an inductance value of 68 µH, making it ideal for smoothing and filtering applications in various electronic devices.

Special Features of the CORE MASTER FPI0504-680M, Power Inductor Include

  • High Inductance Value: 68 µH for superior energy storage and filtering.
  • Compact Size: 5.2 x 5.8 x 4.5 mm, suitable for space-constrained designs.
  • SMD Design: Facilitates automated assembly and improves reliability.
  • Low DC Resistance: Reduces power loss and enhances efficiency.

What Benefits Does It Offer?

  • Improved Circuit Stability: Provides stable inductance to minimise signal interference.
  • Space-Saving Design: Fits easily into compact electronic devices.
  • Enhanced Performance: Low resistance contributes to efficient power management.

Application Areas of the CORE MASTER FPI0504-680M, Power Inductor

  • Power Supply Circuits
  • DC-DC Converters
  • Automotive Electronics
  • RF Circuits
  • Consumer Electronics
