COILCRAFT 0603AF-681XJRW, INDUCTOR 0603 680nH 490mA 5%

0603AF-681XJRW
brand logo

HT Part No. HT194926

Mfr. Part No. 0603AF-681XJRW

Manufacturer: COILCRAFT

Technical Documents: Datasheet(datasheets)

1233 - In Stock pcs
Price:
£ 0.79
Units Per Unit Price
1 - 1999 £ 0.79
2000 + £ 0.69
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Applications General Purpose
Tolerance ±5%
Width 0.80mm
Manufacturer COILCRAFT
Series 0603AF
Shielding Shielded
Diameter N/A
Operation Temperature -40°C ~ +85°C
Mounting Type SMT
Package / Case 0603 (1608 Metric)
Technology Ferrite
DC Resistance (DCR) 460m Ohms
Height 0.80mm
Rohs ROHS
Pitch None
Inductance 680nH
Current Rating 490mA
Current - Saturation (Isat) N/A
Length 1.60mm
Packaging TAPE&REEL

More Information

The COILCRAFT 0603AF-681XJRW is a high-performance inductor designed for applications requiring precise and reliable inductance. This compact 0603-sized component offers a nominal inductance of 680nH and can handle a maximum current of 490mA, making it ideal for space-constrained designs. With a tolerance of 5%, it ensures consistent performance across a range of operating conditions.

Benefits for You

  • Compact 0603 size for space-saving designs
  • High-quality construction for durability
  • Ideal for use in compact electronic devices
  • Ensures reliable performance and minimal energy loss
  • Suitable for high-density PCB layouts

Application Information of the COILCRAFT 0603AF-681XJRW, Power Inductor SMD

  • RF and wireless communication systems
  • Power supply filtering
  • Signal processing circuits
  • General electronic applications requiring precise inductance
