CORE MASTER TPY0705-681M, INDUCTOR FIXED 680UH 7X7MM SMD

TPY0705-681M
brand logo

HT Part No. HT194922

Mfr. Part No. TPY0705-681M

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

1047 - In Stock pcs
Price:
£ 0.25
Units Per Unit Price
1 - 999 £ 0.25
1000 + £ 0.22
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Package / Case Non Standard
Pitch None
Series TPY
Shielding Unshielded
Technology Wire Wound
Current Rating 350mA
Applications General Purpose
Length 7.00mm
Mounting Type SMT
Tolerance ±20%
Operation Temperature N/A
Rohs ROHS
Manufacturer CORE MASTER
Inductance 680uH
Current - Saturation (Isat) N/A
DC Resistance (DCR) 5 Ohms
Diameter N/A
Width 7.00mm
Height 4.60mm
Packaging TAPE&REEL

More Information

The CORE MASTER TPY0705-681M is a high-performance, fixed inductor designed for versatile applications. With a compact 7x7mm surface-mount design, it offers exceptional space efficiency while delivering a reliable inductance of 680µH. This inductor is ideal for use in high-frequency circuits due to its low DC resistance and excellent heat dissipation properties, ensuring stable performance even under demanding conditions. Its robust construction and consistent inductance make it suitable for various electronic applications, from power supply circuits to signal processing.

Where Can I Use the CORE MASTER TPY0705-681M, Fixed Inductor SMD?

  • Power Supply Circuits
  • Signal Processing
  • RF and Communications Equipment
  • Automotive Electronics

Potential Benefits Offered By the CORE MASTER TPY0705-681M, Fixed Inductor SMD

  • Low DC resistance
  • High-frequency performance
  • Excellent heat dissipation
  • Space-saving design
  • Reliable and stable performance
  • Efficient power handling
  • Suitable for high-frequency applications
