MURATA LQW15AN12NJ00D, INDUCTOR FIXED 0402 12nH 500mA SMD

LQW15AN12NJ00D
brand logo

HT Part No. HT194918

Mfr. Part No. LQW15AN12NJ00D

Manufacturer: MURATA

Technical Documents: Datasheet(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 0.18
Units Per Unit Price
10 - 9999 £ 0.18
10000 + £ 0.15
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
DC Resistance (DCR) 140m Ohms
Height 0.50mm
Series LQW15
Package / Case 0402 (1005 Metric)
Current Rating 500mA
Manufacturer MURATA
Tolerance ±5%
Applications General Purpose
Length 1.00mm
Width 0.50mm
Rohs ROHS
Mounting Type SMT
Pitch None
Technology Wire Wound
Shielding Unshielded
Inductance 12nH
Current - Saturation (Isat) N/A
Diameter N/A
Operation Temperature -55°C ~ +125°C
Packaging TAPE&REEL

More Information

The MURATA LQW15AN12NJ00D is a high-performance fixed inductor designed for compact electronic devices. This SMD inductor, measuring just 0402, offers an inductance of 12nH and a maximum current rating of 500mA. Engineered for optimal efficiency, it features low DC resistance and high-frequency performance, making it ideal for high-speed and high-density applications. The LQW15AN12NJ00D is built to withstand temperature fluctuations and provide reliable operation in demanding environments. Its small footprint allows for space-saving designs, and its precise inductance ensures stable performance in signal processing and power supply circuits.

Salient Features and Benefits of Using the MURATA LQW15AN12NJ00D, SMD Fixed Inductor

  • Low DC resistance
  • High-frequency performance
  • Enhanced performance in high-speed applications
  • Reliable operation under varying temperatures
  • Space-efficient design for compact devices

Where Can I Use the MURATA LQW15AN12NJ00D, SMD Fixed Inductor?

  • High-Speed Data Communication Circuits
  • RF and Microwave Applications
  • Power Management Systems
