MURATA LQP15MN2N7B02D, INDUCTOR FIXED 0402 2.7nH 220mA SMD

LQP15MN2N7B02D
brand logo

HT Part No. HT194905

Mfr. Part No. LQP15MN2N7B02D

Manufacturer: MURATA

Technical Documents: Datasheet(datasheets)

8262 - In Stock pcs
Price:
£ 0.19
Units Per Unit Price
2 - 9999 £ 0.19
10000 + £ 0.17
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Current Rating 220mA
Length 1.00mm
Current - Saturation (Isat) N/A
Tolerance ±0.1nH
Operation Temperature -40°C ~ +85°C
Rohs ROHS
Manufacturer MURATA
DC Resistance (DCR) 300m Ohms
Height 0.50mm
Series LQP15
Mounting Type SMT
Package / Case 0402 (1005 Metric)
Shielding Unshielded
Applications General Purpose
Packaging TAPE&REEL
Pitch None
Technology Thin Film
Inductance 2.7nH
Diameter N/A
Width 0.50mm

More Information

The MURATA LQP15MN2N7B02D is a compact 0402 SMD fixed inductor with an inductance value of 2.7nH and a current rating of 220mA. This thin-film inductor offers excellent performance characteristics, including low DC resistance (300mOhm) for efficient power delivery and high Q factor (13 @ 500MHz) for optimal signal integrity. Its small size and surface mount design make it ideal for space-constrained applications.

Possible Advantages of Using the MURATA LQP15MN2N7B02D, Fixed Power Inductor

  • High current handling capability
  • Low power loss due to low DC resistance
  • Excellent high-frequency performance
  • Compact size for space-saving designs
  • Reliable and durable construction

Application Areas of the MURATA LQP15MN2N7B02D, Fixed Power Inductor

  • RF and Microwave Circuits
  • Power Supply Filters
  • Signal Coupling and Decoupling
  • High-Speed Digital Circuits
  • Automotive Electronics
  • Industrial Control Systems
