CORE MASTER TPY0705-100M, INDUCTOR FIXED 10UH 7X7MM SMD

TPY0705-100M
brand logo

HT Part No. HT194885

Mfr. Part No. TPY0705-100M

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

244 - In Stock pcs
Price:
£ 0.25
Units Per Unit Price
1 - 999 £ 0.25
1000 + £ 0.22
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Series TPY
Current - Saturation (Isat) N/A
Tolerance ±20%
Applications General Purpose
Length 7.00mm
Mounting Type SMT
Shielding Unshielded
Inductance 10uH
Width 7.00mm
Package / Case Non Standard
Technology Wire Wound
DC Resistance (DCR) 100m Ohms
Diameter N/A
Height 4.60mm
Manufacturer CORE MASTER
Pitch None
Current Rating 3A
Operation Temperature N/A
Rohs ROHS
Packaging TAPE&REEL

More Information

The CORE MASTER TPY0705-100M is a compact 10uH fixed inductor housed in a 7x7mm SMD package. Designed for efficiency and reliability, this component offers excellent performance in various electronic applications. Its small footprint makes it ideal for space-constrained circuits, while its robust construction ensures durability. With a focus on high current handling and low DC resistance, the TPY0705-100M provides efficient power delivery and minimal heat dissipation.

Standout Features and Benefits of Using the CORE MASTER TPY0705-100M, Power Inductor Fixed

  • High current handling capability
  • Excellent temperature stability
  • Space-saving design
  • Improved circuit performance
  • Reduced power loss
  • Enhanced system reliability

Applications Across Various Fields

  • Power Supply Circuits
  • DC-DC Converters
  • Filter Networks
  • Signal Processing
  • Automotive Electronics
