CORE MASTER TPY0705-220M, INDUCTOR FIXED 22UH 7X7MM SMD

TPY0705-220M
brand logo

HT Part No. HT194882

Mfr. Part No. TPY0705-220M

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

1570 - In Stock pcs
Price:
£ 0.26
Units Per Unit Price
1 - 999 £ 0.26
1000 + £ 0.22
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Package / Case Non Standard
Diameter N/A
Packaging TAPE&REEL
Current Rating 2A
Width 7.00mm
Height 4.60mm
Shielding Unshielded
Length 7.00mm
Manufacturer CORE MASTER
Series TPY
Mounting Type SMT
Pitch None
Current - Saturation (Isat) N/A
Technology Wire Wound
Inductance 22uH
Tolerance ±20%
DC Resistance (DCR) 350m Ohms
Applications General Purpose
Operation Temperature N/A
Rohs ROHS

More Information

The CORE MASTER TPY0705-220M is a high-performance fixed inductor designed for compact SMD applications. Measuring just 7x7mm, this 22µH inductor is engineered to deliver exceptional reliability and efficiency in a variety of electronic circuits. With its low profile and robust construction, it is ideal for space-constrained environments, making it a valuable component for modern electronic devices.

Standout Features and Benefits of Using the CORE MASTER TPY0705-220M, fixed Power Inductor SMD

  • SMD package for space efficiency.
  • Suitable for diverse applications.
  • Designed to withstand demanding conditions.
  • Ensures minimal power loss.
  • Fits easily into compact circuit designs.
  • Provides stable inductance for consistent operation.
  • Reliable under various environmental conditions.

Application Potential of the CORE MASTER TPY0705-220M, fixed Power Inductor SMD

  • Power Supplies
  • Signal Filtering
  • DC-DC Converters
  • RF Circuits
