MURATA LQW18AN7N5D00D, INDUCTOR FIXED 7.5NH 750MA 82 MOHM SMD

LQW18AN7N5D00D
brand logo

HT Part No. HT194881

Mfr. Part No. LQW18AN7N5D00D

Manufacturer: MURATA

Technical Documents: Datasheet(datasheets)

1228 - In Stock pcs
Price:
£ 0.10
Units Per Unit Price
2 - 3999 £ 0.10
4000 + £ 0.089
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Mounting Type SMT
Pitch None
Series LQW18
DC Resistance (DCR) 82m Ohms
Height 0.80mm
Package / Case 0603 (1608 Metric)
Tolerance ±0.5nH
Width 0.80mm
Rohs ROHS
Packaging TAPE&REEL
Inductance 7.5nH
Current - Saturation (Isat) N/A
Diameter N/A
Length 1.60mm
Operation Temperature -55°C ~ +125°C
Manufacturer MURATA
Technology Wire Wound
Shielding Unshielded
Current Rating 750mA
Applications General Purpose

More Information

The MURATA LQW18AN7N5D00D is a fixed inductor with a nominal inductance of 7.5nH, a maximum current rating of 750mA, and a low DC resistance of 82mΩ. This surface-mount device (SMD) is designed for high-frequency applications and offers reliability and stability in electronic circuits.

Potential Advantages of Using the MURATA LQW18AN7N5D00D, Fixed Inductor

  • High Performance: Suitable for high-frequency applications with low signal loss.
  • Compact Design: Saves space on printed circuit boards (PCBs).
  • Reliable: High-quality construction for consistent performance.
  • Energy Efficient: Low DC resistance reduces power loss.

Versatile Uses of the MURATA LQW18AN7N5D00D, Fixed Inductor

  • RF Circuits: Ideal for radio frequency circuits due to their high Q factor.
  • Communication Devices: Utilised in smartphones, tablets, and other wireless communication devices.
  • Power Management: Suitable for DC-DC converters and power supply modules.
  • Automotive Electronics: Applicable in advanced driver-assistance systems (ADAS) and infotainment systems.

Key Features of the Fixed Inductor Include

  • Package Type: Surface Mount Device (SMD)
  • High-Q Factor: Ensures minimal signal loss
  • Compact Size: 0603 (1608 metric) footprint
