CORE MASTER FPI1005-220M, INDUCTOR POWER 22UH 10X9X5.4MM SMD

FPI1005-220M
brand logo

HT Part No. HT194867

Mfr. Part No. FPI1005-220M

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

13562 - In Stock pcs
Price:
£ 0.19
Units Per Unit Price
1 - 499 £ 0.19
500 + £ 0.16
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Technology Power
Current Rating 3.4A
Series FPI
Pitch None
Inductance 22uH
Tolerance ±20%
Mounting Type SMT
DC Resistance (DCR) 70m Ohms
Diameter N/A
Width 9.00mm
Manufacturer CORE MASTER
Shielding Unshielded
Applications General Purpose
Operation Temperature N/A
Rohs ROHS
Packaging TAPE&REEL
Package / Case Non Standard
Current - Saturation (Isat) N/A
Length 10.00mm
Height 5.40mm

More Information

The CORE MASTER FPI1005-220M is a highly efficient inductor power component designed for various electronic applications. With a power rating of 22µH, this inductor is housed in a compact SMD package measuring 10x9x5.4mm. Its robust construction ensures excellent performance in high-frequency applications, making it a reliable choice for modern electronic designs. The FPI1005-220M is characterised by its low DC resistance and high current handling capabilities, ensuring minimal power loss and optimal efficiency.

Significant Benefits of Using the CORE MASTER FPI1005-220M, Power Inductor

  • High current handling capability
  • High-frequency performance
  • Ensures minimal power loss
  • Optimises efficiency in electronic circuits
  • Provides reliable performance in various applications

Wide Application Range

  • Power Supply Circuits
  • DC-DC Converters
  • Consumer Electronics
  • Telecommunications Equipment
  • Industrial Electronics
