CORE MASTER WCI4532-221J-N, INDUCTOR FIXED 220UH 4.2X3.2X3.2MM SMD

WCI4532-221J-N
brand logo

HT Part No. HT194837

Mfr. Part No. WCI4532-221J-N

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 0.15
Units Per Unit Price
1 - 499 £ 0.15
500 + £ 0.13
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Current Rating 100mA
Applications General Purpose
Manufacturer CORE MASTER
Series WCI
Package / Case 1812 (4532 Metric)
Rohs ROHS
DC Resistance (DCR) 10 Ohms
Diameter N/A
Length 4.20mm
Operation Temperature N/A
Mounting Type SMT
Pitch None
Technology Wire Wound
Width 3.20mm
Height 3.20mm
Shielding Shielded
Inductance 220uH
Current - Saturation (Isat) N/A
Tolerance ±5%
Packaging TAPE&REEL

More Information

The CORE MASTER WCI4532-221J-N is a high-performance, fixed inductor designed for efficient power management in compact electronic systems. With a 220µH inductance value and a small 4.2x3.2x3.2mm SMD footprint, this inductor offers a robust and reliable solution for numerous applications. Its optimised design ensures low DC resistance and high current handling capability, contributing to improved system efficiency and performance.

Special Features of the CORE MASTER WCI4532-221J-N, Power Inductor Fixed Include

  • High inductance value in a compact package
  • Low DC resistance for efficient power transfer
  • High current handling capacity
  • SMD package for automated assembly

Benefits for You

  • Improved system performance and efficiency
  • Reduced power loss
  • Enhanced thermal management
  • Simplified PCB design

Versatile Usage of the CORE MASTER WCI4532-221J-N, Power Inductor Fixed Include

  • DC-DC Converters
  • Power Supplies
  • Filter Circuits
  • Automotive Electronics
  • Industrial Control Systems
