GALAXY EM322522-2R2M, INDUCTOR FIXED 1210 2.2UH SMD

EM322522-2R2M
brand logo

HT Part No. HT194833

Mfr. Part No. EM322522-2R2M

Manufacturer: GALAXY

Technical Documents: Datasheet(datasheets)

7662 - In Stock pcs
Price:
£ 0.15
Units Per Unit Price
2 - 1999 £ 0.15
2000 + £ 0.13
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Manufacturer GALAXY
DC Resistance (DCR) 208m Ohms
Packaging TAPE&REEL
Pitch None
Shielding Unshielded
Current Rating 550mA
Height 2.20mm
Series EM
Mounting Type SMT
Package / Case Non Standard
Diameter N/A
Width 2.50mm
Rohs ROHS
Technology Power
Inductance 2.2uH
Current - Saturation (Isat) N/A
Tolerance ±20%
Applications General Purpose
Length 3.20mm
Operation Temperature N/A

More Information

The GALAXY EM322522-2R2M is a high-quality fixed inductor designed for surface-mount applications. It features a compact 1210 package, making it ideal for space-constrained designs. With an inductance of 2.2µH, this SMD inductor provides excellent energy storage and filtering capabilities, ensuring smooth and stable operation in various electronic circuits. The EM322522-2R2M boasts a low DC resistance, minimising power losses and enhancing efficiency.

What Are the Potential Benefits of the GALAXY EM322522-2R2M, Fixed Power Inductor?

  • Compact 1210 SMD package
  • Low DC resistance
  • High current handling capability
  • Durable construction
  • Saves space in compact designs
  • Reduces power losses, improving efficiency
  • Reliable performance in various applications

Application Information of the GALAXY EM322522-2R2M, Fixed Power Inductor

  • Power Supply Circuits
  • DC-DC Converters
  • RF Circuits
  • Signal Filtering and Noise Suppression
  • Consumer Electronics and Communication Devices
