COILCRAFT 0805CS-331XGLC, INDUCTOR FIXED 0805 330nH 5% SMD

0805CS-331XGLC
brand logo

HT Part No. HT194821

Mfr. Part No. 0805CS-331XGLC

Manufacturer: COILCRAFT

Technical Documents: Datasheet(datasheets)

6521 - In Stock pcs
Price:
£ 0.14
Units Per Unit Price
5 - 1999 £ 0.14
2000 + £ 0.12
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Applications Automotive(AEC-Q200)
Width 1.25mm
Series 0805CS
Technology Wire Wound
Manufacturer COILCRAFT
Mounting Type SMT
Tolerance ±2%
DC Resistance (DCR) 1.4 Ohms
Operation Temperature -40°C ~ +125°C
Rohs ROHS
Shielding Shielded
Inductance 330nH
Current Rating 310mA
Diameter N/A
Length 2.00mm
Height 0.80mm
Package / Case 0805 (2012 Metric)
Pitch None
Current - Saturation (Isat) N/A
Packaging TAPE&REEL

More Information

The COILCRAFT 0805CS-331XGLC is a compact, surface-mount inductor designed for high-frequency applications. This SMD component packs a punch in a tiny package, offering an inductance of 330 nano henries with a tolerance of 5%. Engineered for efficiency and reliability, it excels at handling high currents while maintaining low DC resistance.

Potential Advantages of Using the COILCRAFT 0805CS-331XGLC, Surface Mount Power Inductor

  • AEC-Q200 qualified for automotive applications
  • Excellent performance in high-frequency circuits
  • Efficient power transfer
  • Reduced heat dissipation
  • Suitable for demanding environments

Application Versatility of the COILCRAFT 0805CS-331XGLC, Surface Mount Power Inductor

  • RF and Wireless Communication Systems
  • Power Supply Filters
  • Automotive Electronics
  • High-Speed Data Transmission
