CORE MASTER DS3316-100M, INDUCTOR POWER 10uH 12.95X9.40X5.20mm SMD

DS3316-100M
brand logo

HT Part No. HT194817

Mfr. Part No. DS3316-100M

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

6453 - In Stock pcs
Price:
£ 0.35
Units Per Unit Price
1 - 499 £ 0.35
500 + £ 0.31
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Inductance 10uH
Length 12.95mm
Packaging TAPE&REEL
Tolerance ±20%
DC Resistance (DCR) 50m Ohms
Height 5.20mm
Rohs ROHS
Package / Case Non Standard
Current - Saturation (Isat) N/A
Applications N/A
Width 9.40mm
Manufacturer CORE MASTER
Mounting Type SMT
Diameter N/A
Operation Temperature N/A
Series DS3316
Pitch None
Technology Wire Wound
Shielding Unshielded
Current Rating 5.60A

More Information

The CORE MASTER DS3316-100M is a compact power inductor designed for efficient energy storage in electronic circuits. With dimensions of 12.95x9.40x5.20mm, it fits seamlessly into SMD assemblies. This inductor boasts a 10uH inductance, capable of handling substantial currents while maintaining low DC resistance. Its SMD form factor simplifies the manufacturing process and saves board space.

Potential Benefits of the CORE MASTER DS3316-100M, Power Inductor

  • Improved circuit performance through efficient energy management
  • Space-saving design for compact electronic devices
  • Reduced power dissipation for increased efficiency
  • Reliable operation in various electronic systems

Applications Across Various Fields

  • Power Supplies and Converters
  • DC-DC Converters
  • Audio Amplifiers
  • Filter Circuits
  • Motor Control Systems

Special Features of the CORE MASTER DS3316-100M, Power Inductor

  • Compact SMD package for efficient board utilization
  • Low DC resistance for minimal power loss
  • High current handling capacity for demanding applications
