CORE MASTER WHI0402-12NJ-N, INDUCTOR FIXED 0402 12NH SMD

WHI0402-12NJ-N
brand logo

HT Part No. HT194812

Mfr. Part No. WHI0402-12NJ-N

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

5996 - In Stock pcs
Price:
£ 0.12
Units Per Unit Price
1 - 3999 £ 0.12
4000 + £ 0.10
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Pitch None
Technology Wire Wound
Current Rating 640mA
Tolerance ±5%
Series WHI
Mounting Type SMT
DC Resistance (DCR) 120m Ohms
Package / Case 0402 (1005 Metric)
Current - Saturation (Isat) N/A
Height 0.66mm
Rohs ROHS
Packaging TAPE&REEL
Manufacturer CORE MASTER
Applications General Purpose
Diameter N/A
Length 1.19mm
Operation Temperature N/A
Shielding Unshielded
Inductance 12nH
Width 0.64mm

More Information

The CORE MASTER WHI0402-12NJ-N is a surface mount (SMD) fixed inductor with a compact 0402 package size. This component plays a crucial role in electronic circuits by storing energy in a magnetic field and releasing it as needed. Its small footprint makes it ideal for space-constrained designs.

Special Features and Benefits of Using the CORE MASTER WHI0402-12NJ-N, Fixed Power Inductor SMD

  • High Q factor for minimal energy loss
  • Stable inductance over a wide temperature range
  • Suitable for high-frequency applications
  • Improves circuit performance and efficiency
  • Reduces electromagnetic interference (EMI)
  • Enhances signal integrity
  • Facilitates automated assembly processes

Where Can I Use the CORE MASTER WHI0402-12NJ-N, Fixed Power Inductor SMD?

  • RF and Microwave Circuits
  • Power Supply Filters
  • Oscillator Circuits
  • High-Frequency Coupling Networks
