CORE MASTER NR3015-180M, INDUCTOR FIXED 18UH 3X3X1.5MM SMD

NR3015-180M
brand logo

HT Part No. HT194811

Mfr. Part No. NR3015-180M

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

5667 - In Stock pcs
Price:
£ 0.089
Units Per Unit Price
2 - 1999 £ 0.089
2000 + £ 0.073
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Mounting Type SMT
Diameter N/A
Current Rating 620mA
Tolerance ±20%
Applications General Purpose
Package / Case Non Standard
Shielding Shielded
Width 3.00mm
Height 1.50mm
Operation Temperature N/A
Rohs ROHS
Packaging TAPE&REEL
Manufacturer CORE MASTER
Series NR
Pitch None
Technology Wire Wound
Inductance 18uH
Current - Saturation (Isat) N/A
DC Resistance (DCR) 559m Ohms
Length 3.00mm

More Information

The CORE MASTER NR3015-180M is a compact, surface-mount inductor designed for efficient power management in electronic circuits. With a fixed inductance of 18 microhenries and a small footprint of 3x3x1.5 millimetres, this component offers a versatile solution for various applications.

Potential Benefits of Using the CORE MASTER NR3015-180M, Surface-Mount Power Inductor

  • Improves circuit stability and performance.
  • Reduces electromagnetic interference (EMI).
  • Enhances power efficiency.
  • Simplifies PCB layout.

Applications Across Various Fields

  • Power Supply Filters
  • DC-DC Converters
  • Audio Amplifiers
  • RF Circuits
  • Automotive Electronics

Standout Features of the CORE MASTER NR3015-180M, Surface-Mount Power Inductor

  • Compact SMD package for space-saving designs.
  • High current handling capacity.
  • Low DC resistance for minimal power loss.
  • Excellent thermal performance.
