CHILISIN CLH2012T-18NJ-S, INDUCTOR FIXED 0805 18NH SMD

CLH2012T-18NJ-S
brand logo

HT Part No. HT194806

Mfr. Part No. CLH2012T-18NJ-S

Manufacturer: CHILISIN

Technical Documents: Datasheet(datasheets)

3510 - In Stock pcs
Price:
£ 0.024
Units Per Unit Price
20 - 3999 £ 0.024
4000 + £ 0.016
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Inductance 18nH
Packaging TAPE&REEL
Technology Multilayer
Shielding Shielded
Tolerance ±5%
Length 2.00mm
Manufacturer CHILISIN
Current Rating 300mA
Width 1.25mm
Operation Temperature N/A
Rohs ROHS
Package / Case 0805 (2012 Metric)
Current - Saturation (Isat) N/A
DC Resistance (DCR) 450m Ohms
Applications General Purpose
Height 0.80mm
Series CLH
Mounting Type SMT
Pitch None
Diameter N/A

More Information

The CHILISIN CLH2012T-18NJ-S is a fixed inductor with a 0805 package size, offering 18nH inductance. This surface-mount device (SMD) inductor is designed for high-frequency applications and features a compact design and robust construction. The inductor is characterised by its low DCR (Direct Current Resistance) and high Q factor, ensuring efficient energy transfer and minimal energy loss. Additionally, it boasts excellent thermal stability and reliability, making it suitable for demanding environments.

What Are the Key Features and Benefits of Using the CHILISIN CLH2012T-18NJ-S, Fixed Power Inductor?

  • Low DCR for minimal energy loss
  • High Q factor for efficient performance
  • Surface-mount design for easy integration
  • Enhances signal integrity in high-frequency circuits
  • Reduces power consumption
  • Provides reliable performance in varying temperatures

Typical Uses of the CHILISIN CLH2012T-18NJ-S, Fixed Power Inductor

  • RF and Wireless Communication Systems
  • Signal Processing Equipment
  • Automotive Electronics
  • Power Management Circuits
