COILMASTER SDR52-220M-LF, INDUCTOR POWER 22uH 5.8X5.3X2.5mm SMD

SDR52-220M-LF
brand logo

HT Part No. HT194801

Mfr. Part No. SDR52-220M-LF

Manufacturer: COILMASTER

Technical Documents: Datasheet(datasheets)

16729 - In Stock pcs
Price:
£ 0.23
Units Per Unit Price
1 - 1999 £ 0.23
2000 + £ 0.20
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Width 5.30mm
Height 2.50mm
Package / Case Non Standard
Shielding Shielded
Current Rating 730mA
Rohs ROHS
Manufacturer COILMASTER
Mounting Type SMT
Pitch None
Current - Saturation (Isat) N/A
Tolerance ±20%
Technology Wire Wound
Applications Automotive(AEC-Q200)
Diameter N/A
Length 5.80mm
Operation Temperature -40°C ~ +125°C
Series SDR
Inductance 22uH
DC Resistance (DCR) 248m Ohms
Packaging TAPE&REEL

More Information

The COILMASTER SDR52-220M-LF is a high-performance power inductor designed for efficient energy storage and smooth current flow in electronic circuits. This SMD inductor boasts an inductance of 22µH, with compact dimensions of 5.8 x 5.3 x 2.5 mm, making it ideal for space-constrained applications. Its robust construction ensures high reliability and durability, while the low DC resistance and high current rating contribute to its superior performance. The SDR52-220M-LF is perfect for use in power management applications, filtering, and energy storage in various electronic devices.

Significant Benefits of Using the COILMASTER SDR52-220M-LF, Power Inductor SMD

  • High current rating
  • High reliability and durability
  • Efficient energy storage
  • Smooth current flow
  • Space-saving design
  • Enhanced performance in electronic circuits

Application Versatility of the Power Inductor SMD

  • Power Management
  • Filtering
  • Energy Storage
  • DC-DC Converters
  • Consumer Electronics
  • Communication Devices
