KWANG SUNG AL02TB100K, 10uH 10mm %10 Q=30 SRF=50Mhz I=100mA AXIAL KSUNG

AL02TB100K
brand logo

HT Part No. HT194799

Mfr. Part No. AL02TB100K

Manufacturer: KWANG SUNG

Technical Documents: Datasheet(datasheets)

18639 - In Stock pcs
Price:
£ 0.048
Units Per Unit Price
2 - 2499 £ 0.048
2500 + £ 0.040
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Shielding Unshielded
Current Rating 160mA
DC Resistance (DCR) 2.3 Ohms
Technology Wire Wound
Inductance 10uH
Length 3.40mm
Mounting Type THT
Current - Saturation (Isat) N/A
Height N/A
Package / Case Axial
Pitch None
Operation Temperature -25°C ~ +105°C
Rohs N/A
Manufacturer KWANG SUNG
Series AL02
Tolerance ±10%
Applications General Purpose
Diameter 2.50mm
Width N/A
Packaging AMMO BOX

More Information

The KWANG SUNG AL02TB100K is a high-performance inductor designed for precision electronic applications. With an inductance of 10uH, a 10mm tolerance of ±10%, and a Q factor of 30, this component ensures stable and reliable performance. The Self-Resonant Frequency (SRF) of 50MHz and a current rating of 100mA make it suitable for high-frequency circuits and applications requiring minimal signal loss. Its axial construction allows for easy integration into various circuit boards, enhancing versatility and efficiency.

What are the Possible Advantages of the KWANG SUNG AL02TB100K, Power Inductor?

  • Self-Resonant Frequency (SRF)
  • Axial construction for easy integration
  • High-frequency stability
  • Reliable performance in precision applications
  • Easy to integrate into various circuit designs
  • Minimal signal loss due to high Q factor

Versatility in Applications

  • High-Frequency Circuits
  • Signal Processing
  • RF Circuits
  • Power Supply Filtering
  • Telecommunications Equipment
