CORE MASTER FPI0504-100M, INDUCTOR POWER 10UH 5.2X5.8X4.5MM SMD

FPI0504-100M
brand logo

HT Part No. HT194796

Mfr. Part No. FPI0504-100M

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 0.10
Units Per Unit Price
1 - 1499 £ 0.10
1500 + £ 0.089
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Pitch None
Tolerance ±20%
Height 4.50mm
Technology Power
Shielding Unshielded
Inductance 10uH
Packaging TAPE&REEL
Series FPI
DC Resistance (DCR) 100m Ohms
Diameter N/A
Operation Temperature N/A
Package / Case Non Standard
Applications General Purpose
Length 5.80mm
Rohs ROHS
Manufacturer CORE MASTER
Mounting Type SMT
Current Rating 2.3A
Current - Saturation (Isat) N/A
Width 5.20mm

More Information

The CORE MASTER FPI0504-100M is a high-performance SMD power inductor designed to meet the rigorous demands of modern electronic devices. With a compact size of 5.2x5.8x4.5mm, this 10µH inductor is ideal for applications requiring efficient energy storage and low resistance. It boasts a robust construction that ensures durability and reliability in various environments. The inductor's low DC resistance minimises power loss, enhancing overall efficiency. It also offers excellent thermal stability, making it suitable for high-temperature operations. The CORE MASTER FPI0504-100M is optimised for use in various applications, providing stable performance and contributing to the longevity of electronic systems.

Unique Features and Benefits of Using the CORE MASTER FPI0504-100M, Power Inductor SMD

  • Excellent thermal stability
  • High reliability
  • Efficient energy storage
  • Reduced power loss
  • Suitable for high-temperature environments
  • Enhances overall system performance

Application Areas of the SMD Power Inductor

  • Power Management Systems
  • DC-DC Converters
  • Filtering Applications
  • Portable Electronic Devices
  • Automotive Electronics
