COILMASTER SDB0705H-331K-LF, INDUCTOR POWER 330UH 7X7X4.6MM SMD

COILMASTER SDB0705H-331K-LF, INDUCTOR POWER 330UH 7X7X4.6MM SMD
SDB0705H-331K-LF
brand logo

HT Part No. HT194794

Mfr. Part No. SDB0705H-331K-LF

Manufacturer: COILMASTER

Technical Documents:

6 - In Stock pcs
Price:
£ 0.39
Units Per Unit Prices
1 - 999 £ 0.39
1000 + £ 0.35
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Diameter N/A
Applications General Purpose
Width 7.00mm
Package / Case Non Standard
Inductance 330uH
Rohs ROHS
Packaging TAPE&REEL
Manufacturer COILMASTER
Series SDB
Mounting Type SMT
Current Rating 320mA
DC Resistance (DCR) 1.1 Ohms
Length 7.00mm
Pitch None
Technology Power
Shielding Unshielded
Current - Saturation (Isat) N/A
Tolerance ±10%
Height 4.60mm
Operation Temperature -40°C ~ +125°C

More Information

The COILMASTER SDB0705H-331K-LF is a high-performance power inductor ideal for various electronic applications. This inductor features a compact size of 7x7x4.6mm and an SMD (Surface Mount Device) design, making it perfect for modern, space-constrained circuit boards. With a robust inductance of 330µH, it ensures efficient energy storage and smooth current flow. The COILMASTER SDB0705H-331K-LF is known for its low DC resistance and high saturation current, which minimises power loss and maximises efficiency.

Potential Advantages of Using the COILMASTER SDB0705H-331K-LF, Power Inductor

  • High saturation current
  • Space-saving for compact circuit designs
  • Enhanced energy efficiency
  • Reduced power loss
  • Reliable performance in demanding conditions

Wide Range of Applications

This versatile inductor is an excellent choice for engineers and designers seeking reliability and performance in their power management solutions, such as:

  • Power Supply Circuits
  • DC-DC Converters
  • Portable Electronic Devices
  • Communication Equipment
