CORE MASTER HCL1608-R22J-N, INDUCTOR FIXED 0603 220nH SMD

HCL1608-R22J-N
brand logo

HT Part No. HT194793

Mfr. Part No. HCL1608-R22J-N

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

4515 - In Stock pcs
Price:
£ 0.032
Units Per Unit Price
10 - 3999 £ 0.032
4000 + £ 0.024
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Shielding Unshielded
Height 0.80mm
Diameter N/A
Operation Temperature N/A
Pitch None
Current Rating 250mA
Length 1.60mm
Packaging TAPE&REEL
Series HCL
Mounting Type SMT
Package / Case 0603 (1608 Metric)
Current - Saturation (Isat) N/A
Tolerance ±5%
Width 0.80mm
Manufacturer CORE MASTER
Technology Multilayer
Inductance 220nH
DC Resistance (DCR) 2 Ohms
Applications General Purpose
Rohs ROHS

More Information

The CORE MASTER HCL1608-R22J-N is a high-performance, fixed inductor with a 220nH inductance, designed explicitly for surface-mount device (SMD) applications. Encased in a compact 0603 package, it is ideal for space-constrained designs. This inductor boasts a low DC resistance, ensuring minimal power loss and high efficiency in power conversion applications. The HCL1608-R22J-N is constructed with high-quality materials that provide excellent thermal stability and reliability, making it suitable for a wide range of temperature environments. Its robust design also ensures it can withstand high current loads without compromising performance.

Benefits You Get

  • Excellent thermal stability
  • High current handling capacity
  • Enhances power conversion efficiency
  • Saves space in compact electronic designs
  • Reliable performance in varied temperature conditions
  • Reduces power loss

Where to Use the CORE MASTER HCL1608-R22J-N, Power Inductor Fixed?

  • Power Supplies
  • DC-DC Converters
  • RF Circuits
  • Mobile Devices
  • Consumer Electronics
